Ürün ayrıntıları:
|
|
Menşe yeri: | ÇİN |
---|---|
Marka adı: | Glawall |
Sertifika: | SGS, ISO 9001,UL, CE |
Model numarası: | Tamamen modüler çift cam duvar |
Belge: | 25mm.pdf |
Ödeme & teslimat koşulları:
|
|
Min sipariş miktarı: | 10 Kare Malzeme |
Fiyat: | US$80.00 10 - 99 square meters |
Ambalaj bilgileri: | kontrplak |
Teslim süresi: | 20-25 gün |
Ödeme koşulları: | L/C, D/A, D/P, T/T, Western Union |
Yetenek temini: | Ayda 3000 metrekare |
Detay Bilgi |
|||
Avantaj: | Rekabetçi fiyat, iyi hizmet, yüksek profesyonel, kalite garantisi | ORIGI YERİ: | Guangdong, Çin |
---|---|---|---|
Fabrika sertifikası: | Evet | Fabrika alanı: | 20000 metrekare |
Malzeme: | Alüminyum Çerçeve, Akustik Paneller | Ses yalıtımı: | 38-45dB |
Panel kalınlığı: | 60, 90.108mm | Cam tipi: | güçlü temperli cam |
Havalandırma: | Hava Akış Sistemi | Garanti: | 2 yıl |
Vurgulamak: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system |
Ürün Açıklaması
Advantage | Competitive price, good service, high professional, quality guarantee |
Place of Origin | Guangdong, China |
Factory Certification | Yes |
Factory Area | 20000 square meter |
Material | Aluminum Frame, Acoustic Panels |
Soundproofing | 38-45dB |
Panel Thickness | 60, 90, 108mm |
Glass Type | Strong tempered glass |
Ventilation | Airflow System |
Warranty | 2 Years |
Feature | Benefit |
---|---|
Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
Tool-Free Connection | Patented click-lock system secures panels without tools |
Fast Installation | 2-person team can install 20m² in under 3 hours |
42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
Step | Action |
---|---|
Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
Step 3 | Snap decorative covers over joints for perfect alignment |
Feature | Specification |
---|---|
Frame | 90mm powder-coated aluminum (20+ RAL colors) |
Glass | 5+5mm tempered (clear/frosted/tinted options) |
Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
Fire Rating | EI30-EI60 available |
Max Height | 4m without additional support |
For Contractors | For Clients |
---|---|
70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
